• Laser-cut joints, automatic welding and polishes. Screws hidden from view.
• Double walled lid balanced by means of a hinge with front handle, with diagonal opening to 75° which allows the lid to be kept open in any position.
• Tank inbuilt into the surface top by robotic welding, manufactured in AISI-304 stainless steel, with the bottom of the tank in AISI-316L stainless steel.
• Tank filling with hot or cold water by electrovalve, activated with a single switch located on the front panel.
• Tank emptying by 2” safety valve with handle in athermic material and safe and effortless handling.
• Robust and reliable filter for draining the tank manufactured in AISI-304 stainless steel. Easily extractable.
• Controls with protective base and system against water infiltration.
• High temperature enamelled cast iron flue protector.
• Access to the components from the front.
• Machines with IPX5 grade water protection.
• Group of sequentially operating, optimized combustion stainless steel tubular burners, controlled by energy regulator.
Pressure gas models
• Heating from the burners at the bottom of the pan covers the base in a uniform manner, to give progressive heating of the contents of the tank.
• Option of regulating the heating by the burners, with different degrees of power.
• Ignition of group of burners by spark train.There is also an access tube for manual ignition.
• Indicator light to show when the machine is connected and when it is heating.
